The KNX configuration tool is pracical for fast and convenient commissioning of KNX components, planned in. The connection to the KNXbus via connectors. When using the connection module CM.1.1.1, KNX connections can also simply stuck on the distribution side. The integrated KNX power supply is shiftable. KNX components can also be programmed without existing infrastructure of the KNX. The coupling of the KNX works via a LAN port or the WLAN access point. Through the wireless connection via the ETS, you can move freely with the notebook to programm it. With its compact dimensions and the included toolbox is the KNX commissioning tool hit the ideal companion for the system integrator.
Features included: - KNX IP interface - WLAN access point - LAN switch -KNX Powersupply 320 mA (shiftable) -Box for tools
Touch_IT C3 3,5" TFT Display with Touchscreen metal housing
3,5' display in metal housing for visualization and controlling via KNX-Bus.
It will be mounted with a support ring , magnets and a safety screw in a standard box (68mm) in wall.
Hardware: - 3,5" - TFT-Color Display with 320xRGBx240 (256K Color) and Touchscreen - 200MHz 32-Bit ARM9 Prozessor - Linux OS - Adjustable LED-Backlight - Alarm signal - ETS-programmable - 5 display pages, each with up to 8 control elements - For each element up to 4 KNX objects used - Wide range of Control elements Pushbuttons / switches ( opt. with status report ) Slidecontroller, +/- push button for value settings ( Set points etc. ) - Elements for dimming with switching function shutter/blinds controller, clock timer, timer etc. - Additional display page for alarm objects - Each page and each control element can be protected by password - Various user interfaces, layouts and standby options selectable on the device - Different font sizes adjustable - Customizing aplicable
EIB/KNX-elements: - up to 196 objects - System objects: time / date Brightness Temperature Alarm
Applications: - Switching and dimming of lighting - Display of the switching status in building - Control of various devices in the KNX-Bus - Handling of shutters/blinds - Alarm functions acoustic and optical - Display of motion detector alarms as plain text - Display and setting of heating control - Control of multi room audio-systems - Display of Temperatures - Weekly time clock
Connection: - Auxiliary supply DC 9-32 V, ca. 1,5 VA,
Ambient Temperature: Storage -5...+60 °C, Operating -5...+55 °C
INVOX: voice control system based on natural language.
INVOX: voice control system based on natural language.
INVOX allows you to control a KNX system via vocal orders using a flexible and open language. You don’t need to memorize or save commands. And there is no need for training either.
With INVOX you can control your home using only your voice, the kind of communication you use daily in order to communicate with others (ex.: “turn out the kitchen lights”, “lift the blinds a bit” or “higher temperature up to 24ºC”, “lower the volume”, etc.). Control your house from your favourite coach the simplest way: giving instructions as if you were talking to your butler.
INVOXuses a new technology developed by VÓCALI.
The INVOXEditor (ICE) is the software used to create the configuration file that INVOX needs in order to recognize the user’s commands.
KNX temperature and humidity sensor with two push buttons, White
The Indoor Sensor KNX TH-B-UP measures temperature and humidity and calculates the dew point. The sensor can receive external measured values via the bus and process them with the own data to an overall temperature and overall air humidity (mixed values). The KNX TH-B-UP offers two push buttons for changing the ambient temperature (target value).
The KNX TH-B-UP provides seven switching outputs with adjustable threshold values as well as additional AND and OR logic gates. The sensor has got a PI controller for heating and cooling (depending on temperature) and for ventilation (depending on air humidity) and it can emit a warning to the bus as soon as the area of optimum comfort (according to DIN 1946) is left.
The integrated display shows the own values and data received from the bus (e. g. date, time). The housing is completed with a frame of the switching series installed in the building and thus merges with the interior.
Functions and Operation
· Measurement of temperature and air humidity (relative, absolute), calculation of dew point · Mixed values from own measured values and external values (proportions can be set in percentage) · Display 1-3 rows (own values or values received from the bus) · 2 push buttons for changing the ambient temperature at the device. The step size can be adjusted from 0,1°C to 5°C. · PI controller for heating (one or two step) and cooling (one or two step) depending on temperature · PI controller for ventilation depending on humidity: Dehumidify/humidify (one step) or dehumidify (one or two step) · 7 switching outputs with adjustable threshold values (Threshold values can be set by parameter or via communication objects) · 4 AND and 4 OR logic gates with each 4 inputs. Every switching incident as well as 8 logic inputs (in the form of communication objects) may be used as inputs for the logic gates. The output of each gate may optionally be configured as 1 bit or 2 x 8 bits · Configuration is accomplished by means of the KNX software ETS
